MY-Q807

1.
80MM kiosk thermal receipt printer
2.
Tight structure, easy installation
3.
Stable performance and easy maintenance
4.
USB or serial port optional
5.
Automatic paper cutting, large paper warehouse capacity
6.
Support paper removal detection, paper will be ended detected
收藏
  • Description
  • Parameters


ItemMY-Q807
PrintingPrint methodUSB+RS232/USB+TTL
ResolutionThermal Line Printing
Printing speed203Dpi(8dot/mm)
 Printing width 150mm/s
Interface port72mm(576dots)
Serial port settingBaud rate:9600  Data bits:8  Stop bit:1 Parity bit:No
PaperTypeThermal receipt paper
Width79.5±0.5mm
Roll paper diameterMax.100mm
Thickness0.05-0.1mm
Tearing PaperAuto Cutting(partial cutting)
ReliabilityTPH life50km
FontChineseGBK:16x16,24x24
Western ASCII:8x16,9x17,9x24,12x24
Barcode1D codeUPC-A,UPC-E,EAN8,EAN13,code39,ITF,CODEBAR,CODE128,CODE93
2D codeQR code,PDF417
PowerInput   DC12V/2.5A  DC24V/2.5A
SoftwareEmulationESC/POS
DriverWindows XP、7、8、10、11/ Linux
SDKWindows SDK/Linux SDK/Android SDK
EnvironmentOperating temperature-10°C-50°C
Operating humidity20%RH-85% RH
Storage temperature-20°C-60°C
Storage humidity5%-90%RH
Overall size(LxWxH)118*47*180mm
Weight(KG)0.85KG
