MY-D421

Model		MY-D421
Printing	Interface port	USB+Ethernet+Bluetooth+WIFI
	Print method	Thermal Line Printing
	Resolution	203Dpi(8dot/mm)
	Printing speed	100mm/s
	Printing width	108mm（864dots）
	Serial port setting	Baud rate：9600 Data bits：8 Stop bit：1 Parity bit：No
Paper	Type	Thermal receipt/label paper
	Width	40-118mm(adjustable)
	Roll paper diameter	Max.100mm
	Thickness	0.053-0.15mm
	Loading Paper	Easy paper & Automatic paper feed
	Tearing Paper	Auto Cutting(full cutting/partial cutting)
Reliability	TPH life	100km
	Cutter life	1 million times
Font	Chinese	GBK:16x16,24x24
	Western	ASCII:8x16,9x17,9x24,12x24
Barcode	1D code	UPC-A,UPC-E,EAN8,EAN13,code39,ITF,CODEBAR,CODE128,CODE93
	2D code	QR code,PDF417
Memory	RAM	64M
	Flash	128M
Power	input	DC 24V/2A
Software	Emulation	ESC/POS(Receipt) CPCL、TSPL、JPL(Label)
	Driver	Windows XP、7、8、10/ Linux/MAC OS
	SDK	Windows SDK/Linux SDK/Android SDK/IOS SDK
Environment	Operating temperature	-10°C-50°C
	Operating humidity	20%RH-85% RH
	Storage temperature	-20°C-60°C
	Storage humidity	5%-90%RH
Overall size(LxWxH)	Without paper roll	230178.6160.8mm
Weight（KG）		1.3KG
